PostgREST v10: EXPLAIN and Improved Relationship Detection

2022-08-19

8 minute read

PostgREST turns your PostgreSQL database automatically into a RESTful API. Today, PostgREST v10 was released. v10 is not available on the Supabase Platform yet, but it is available for self-hosting or as a executable binary from the GitHub release page.

Let's take a look at some of its new features that go hand in hand with supabase-js v2.

EXPLAIN

Akin to the PostgreSQL EXPLAIN command, you can now get the execution plan of a request through HTTP or supabase-js. This works transparently for reads, writes and RPC because every request to PostgREST generates a single SQL query.

This is only suitable for development environments and is only enabled when the db-plan-enabled config is set to true.

Getting the execution plan through HTTP

Using curl, you can obtain the execution plan by specifying a vendor media type on the Accept header.


_10
$ curl -H 'Accept: application/vnd.pgrst.plan' \
_10
'https://<project>.supabase.co/rest/v1/clients?select=*&id=eq.1'
_10
_10
Aggregate (cost=8.18..8.20 rows=1 width=112)
_10
-> Index Scan using clients_pkey on clients (cost=0.15..8.17 rows=1 width=36)
_10
Index Cond: (id = 1)

The text format is used by default, which gives you the same output you’d get in other SQL clients like psql. You can change the format to JSON by using a media type suffix application/vnd.pgrst.plan+json.

Explaining supabase-js queries

For supabase-js, you can get the execution plan using the explain() transform. This works for every supabase-js method, including rpc(). Here’s an example for select().


_10
const { data, error } = await supabase
_10
.from('projects')
_10
.select('*')
_10
.eq('id', 1)
_10
.explain()
_10
_10
console.log(data)

hideCopy

_10
Aggregate (cost=8.18..8.20 rows=1 width=112)
_10
-> Index Scan using projects_pkey on projects (cost=0.15..8.17 rows=1 width=40)
_10
Index Cond: (id = 1)

Explaining the plan output in detail is beyond the scope of this blog post but basically it’s a tree of operations that PostgreSQL will follow for executing a query. Here we see the “Aggregate” node which corresponds to the json_agg function used by the PostgREST generated query(more details on how to find these later) and the “Index Scan” node which means an index on “id” was used for a fast search.

Explaining RLS policies

The raison d'etre of explain() is to provide quicker feedback on the performance of queries, especially in the presence of RLS policies. For instance, let’s say we have this basic policy:


_10
create policy "anon can't read"
_10
on projects for select to anon
_10
using (
_10
false
_10
);

And we use explain() again, this time with the analyze option(executes the query, same as the EXPLAIN ANALYZE counterpart in SQL) so we can see the execution time.


_10
const { data, error } = await supabase
_10
.from('projects')
_10
.select('*')
_10
.eq('id', 1)
_10
.explain({ analyze: true })
_10
_10
console.log(data)

hideCopy

_10
Aggregate (cost=8.18..8.20 rows=1 width=112) (actual time=0.017..0.018 rows=1 loops=1)
_10
-> Index Scan using projects_pkey on projects (cost=0.15..8.17 rows=1 width=40) (actual time=0.012..0.012 rows=0 loops=1)
_10
Index Cond: (id = 1)
_10
Filter: false
_10
Rows Removed by Filter: 1
_10
Planning Time: 0.092 ms
_10
Execution Time: 0.046 ms

Here you can see the “Filter” node, which is a simple false as defined by the above policy, this proves that the RLS policy is getting applied. Also the actual “Execution Time” is shown, which is a fraction of a millisecond. Note that this is only the query execution time, it doesn’t account for the latency for transferring the data from the database to the frontend.

Getting the Query Identifier

explain() is also useful for getting the pg_stat_statements query identifier, which you can use in the Supabase logs to obtain the generated SQL queries. Here we use the json format and the verbose option to get it.


_10
const { data, error } = await supabase
_10
.from('projects')
_10
.select('*')
_10
.eq('id', 1)
_10
.explain({ format: 'json', verbose: true })
_10
_10
console.log(data[0]['Query Identifier'])
_10
// 2811722635570756600

For getting more detailed information, you can also use the settings, buffers, wal options with explain() .

Improved Relationship Detection

One-to-one relationships

To avoid unnecessary JSON arrays in a query result, one-to-one relationships are now automatically detected. For this you can use a:


_24
-- A unique constraint on a foreign key
_24
create table country (
_24
id serial primary key,
_24
name text
_24
);
_24
_24
create table capital (
_24
id serial primary key,
_24
name text,
_24
country_id int unique,
_24
foreign key (country_id) references country (id)
_24
);
_24
_24
-- or a primary key on a foreign key
_24
create table country (
_24
id serial primary key,
_24
name text
_24
);
_24
_24
create table capital (
_24
id serial primary key,
_24
name text,
_24
foreign key (id) references country (id)
_24
);

Both options should give you a json object when embedding one table with the other.


_10
const { data, error } = await supabase
_10
.from('country')
_10
.select('name,capital(name)')
_10
.in('id', [1, 2])
_10
_10
console.log(data)

noCopy

_10
[
_10
{ "name": "Afghanistan", "capital": { "name": "Kabul" } },
_10
{ "name": "Algeria", "capital": { "name": "Algiers" } }
_10
]

Computed relationships

PostgREST uses foreign keys to detect relationships. This poses a problem on database objects that cannot have foreign keys, like views. Though PostgREST tries to infer relationships based on the views’ source tables foreign keys(docs), this is not infallible - in particular, it fails when views have a complex definition (e.g. multiple UNIONs). For this you can use “computed relationships”, which are “inlinable” SQL functions similar to computed columns.

Let’s assume we have a players view, a scores materialized view and we want to define a one-to-many relationship on them.


_16
create view players as
_16
select id, name from players_a
_16
union
_16
select id, name from players_b;
_16
_16
create materialized view scores as
_16
select
_16
name as lvl_name,
_16
compute_score(stats) as total, player_id
_16
from level_1;
_16
union
_16
select
_16
name as lvl_name,
_16
compute_score(stats) as total,
_16
player_id
_16
from level_2;

For this we can define a couple of computed relationships.


_19
-- many-to-one relationship on scores -> players
_19
create function player(scores)
_19
returns setof players rows 1 -- rows 1 defines a "one" end
_19
language sql stable
_19
as $$
_19
select *
_19
from players
_19
where id = $1.player_id;
_19
$$;
_19
_19
-- one-to-many relationship on players -> scores
_19
create function scores(players)
_19
returns setof scores -- there's an implicit rows 1000 here, which is assumed to be "many"
_19
language sql stable
_19
as $$
_19
select *
_19
from scores
_19
where player_id = $1.id;
_19
$$;

And now we can embed both views from one end to the other. Note that the function names are arbitrary, here we named them similar to the views for convenience.


_28
const { data, error } = await supabase
_28
.from('scores')
_28
.select('lvl_name, player(name)')
_28
.eq('lvl_name', "Grand Prix 1")
_28
.single()
_28
_28
console.log(data)
_28
_28
{
_28
"lvl_name": "Grand Prix 1",
_28
"player": { "name": "Ben Richards"}
_28
}
_28
_28
const { data, error } = await supabase
_28
.from('players')
_28
.select('name,scores(lvl_name, total)')
_28
.eq('id', 1)
_28
.single()
_28
_28
console.log(data)
_28
_28
{
_28
"name":"Ben Richards",
_28
"scores":[
_28
{"lvl_name": "Grand Prix 1", "total": 48761.24},
_28
{"lvl_name": "Grand Prix 2", "total": -40.25}
_28
]
_28
}

Computed relationships follow the rules of Inlining of SQL Functions, which basically allows them to be injected into PostgREST generated queries, making them efficient to use. You can also use computed relationships to override detected relationships.

Breaking change on many-to-many relationships

Detecting join tables for many-to-many relationships has been working for many releases. However on complex schemas join tables can be incorrectly detected, causing errors when used in resource embedding. For this the following BREAKING CHANGE had to be made:


_19
-- for "books_authors" to be detected as a join table,
_19
-- the primary key must include the foreign key columns
_19
-- of the many-to-many ends
_19
_19
create table books (
_19
id int primary key,
_19
name text
_19
);
_19
_19
create table books_authors (
_19
book_id int references books (id),
_19
author_id int references authors (id),
_19
primary key (book_id, author_id) -- this is now necessary
_19
);
_19
_19
create table authors (
_19
id int primary key,
_19
name text
_19
);

If changing the PK is not feasible for a particular case, the alternative would be using computed relationships to define the many-to-many.

One-to-many and many-to-one relationships keep working as always, no change in their detection.

Closing up

Computed relationships are the first step towards PostgREST extensibility, customizing the aggregate used for the response and custom operators are planned for next releases.

We’ll release PostgREST 10 on the Supabase platform over the next month.
