Exploring Support Tooling at Supabase: A Dive into SLA Buddy

2024-04-25

15 minute read

Introduction

In database management and support operations, ensuring Service Level Agreement (SLA) compliance is paramount. Supabase, known for its innovative approach to database management and support, introduces SLA Buddy, a robust support tool aimed at efficient SLA enforcement. This blog post delves into the intricacies of SLA Buddy, shedding light on its functions, operations, and interactions within the Supabase ecosystem.

Introducing SLA Buddy

Supabase's commitment to innovation extends beyond database solutions; it encompasses robust support operations. SLA Buddy stands as a testament to Supabase's dedication to streamlining support processes and ensuring timely resolution of user queries.

Dogfooding: The Birth of SLA Buddy

Supabase firmly believes in dogfooding a philosophy that entails using one's own products internally. This approach played a pivotal role in the creation of SLA Buddy. Leveraging Supabase's suite of tools, including Edge Functions and Database functionalities, SLA Buddy was meticulously developed to meet the stringent demands of support operations.

Understanding SLA Buddy's Functions

SLA Buddy's core function revolves around enforcing SLAs effectively. Let's delve into its primary functions:

SLA Enforcement

SLA Buddy ensures SLA compliance through a series of intricate processes. This includes:

  • Slack Reminders: Utilizing Slack reminders to prompt support engineers about impending SLA deadlines.
  • Calendar Checks: Employing calendar integration to determine who's currently available to answer support tickets.

Let's take a look at SLA Buddy's Operations

To gain a deeper understanding of SLA Buddy's operations, let's take a look on the main diagram of operations: SLA Buddy Operations

Watching Messages

SLA Buddy actively monitors Slack channels using PostgreSQL functions like process_channels. This function scans Slack channels, handles new messages, and adds tasks to the queue for each new ticket that comes to the platform. Once the channel is scanned through the scan_channel edge function it adds rows to the slack_watcher table. There is a trigger function on that table that creates tasks for each ticket according to the SLA which depends on which channel that the message came from. Tickets have different SLAs, depending on both severity and the subscription level of the user opening the ticket.


_45
CREATE OR REPLACE FUNCTION "public"."insert_tasks"() RETURNS "trigger"
_45
LANGUAGE "plpgsql"
_45
AS $$
_45
declare
_45
escalationtimeintervals int[];
_45
currentinterval int;
_45
threadts text;
_45
_45
BEGIN
_45
IF new.channel_id <> '' THEN
_45
SELECT escalation_time INTO escalationtimeintervals
_45
FROM priority WHERE channel_id = new.channel_id;
_45
ELSE
_45
escalationtimeintervals := array[10, 20, 35, 50]; -- minutes
_45
END IF;
_45
-- INSERT tasks for each escalation level
_45
FOR i IN 1..4
_45
LOOP
_45
-- set the current escalation time interval
_45
currentinterval := escalationtimeintervals[i];
_45
-- format thread_ts as (epoch time as a big int) + '.' + ts_ms
_45
thread_timestamp := extract(epoch FROM new.ts)::bigint::text || '.' || new.ts_ms;
_45
_45
-- check IF ticket_type is not 'feedback'
_45
IF lower(new.ticket_type) <> 'feedback' THEN
_45
INSERT INTO checking_tasks_queue (http_verb, payload, due_time, replied)
_45
values (
_45
'POST',
_45
jsonb_build_object(
_45
'channel_id', new.channel_id,
_45
'thread_ts', thread_timestamp,
_45
'escalation_level', i,
_45
'ticket_id', new.ticket_number,
_45
'ticket_priority', new.ticket_priority,
_45
'ticket_type', new.ticket_type
_45
),
_45
new.ts + (currentinterval * interval '1 minute'),
_45
false
_45
);
_45
END IF;
_45
END LOOP;
_45
-- return the new slack_msg row
_45
return new;
_45
END;
_45
$$;

Verifying Due Tasks

The core function check_due_tasks_and_update() plays a pivotal role in task verification and status updating. It ensures that tasks are duly acknowledged, thereby facilitating timely resolution.


_90
CREATE OR REPLACE FUNCTION "public"."check_due_tasks_and_update"() RETURNS "void"
_90
LANGUAGE "plpgsql"
_90
AS $$
_90
DECLARE
_90
_task RECORD;
_90
_response JSONB;
_90
_response_row JSONB;
_90
_ticket_id text;
_90
_have_replied BOOLEAN;
_90
_ticket_array text;
_90
_lock_key CONSTANT int := 42;
_90
_lock_acquired boolean;
_90
BEGIN
_90
-- Try to acquire the advisory lock
_90
_lock_acquired := pg_try_advisory_lock(_lock_key);
_90
IF NOT _lock_acquired THEN
_90
RAISE NOTICE 'Could not acquire lock. Another instance is running. Exiting function...';
_90
RETURN;
_90
END IF;
_90
_90
-- Call create_ticket_array()
_90
RAISE NOTICE 'Calling create_ticket_array()';
_90
_ticket_array := public.create_ticket_array();
_90
_90
-- Check IF _ticket_array is '[]'
_90
IF _ticket_array = '[]' THEN
_90
RAISE NOTICE 'No tickets to process. Exiting function...';
_90
-- Release the advisory lock
_90
PERFORM pg_advisory_unlock(_lock_key);
_90
RETURN;
_90
END IF;
_90
_90
-- Call help_plataform_wrapper() using _ticket_array
_90
RAISE NOTICE 'Calling help_plataform_wrapper()';
_90
_response := public.help_plataform_wrapper(_ticket_array);
_90
_90
-- Check IF _response is NULL
_90
IF _response IS NULL THEN
_90
RAISE NOTICE 'Response is NULL. Exiting function...';
_90
-- Release the advisory lock
_90
PERFORM pg_advisory_unlock(_lock_key);
_90
RETURN;
_90
END IF;
_90
_90
-- Process the response
_90
FOR _response_row IN SELECT * FROM jsonb_array_elements(_response)
_90
LOOP
_90
_ticket_id := _response_row->>'ticket_id';
_90
_have_replied := (_response_row->>'have_replied')::BOOLEAN;
_90
RAISE NOTICE 'Processing response for ticket_id: %, have_replied: %', _ticket_id, _have_replied;
_90
IF _have_replied THEN
_90
RAISE NOTICE 'Ticket % has a reply. Updating...', _ticket_id;
_90
-- Perform actions for replied tickets
_90
UPDATE public.checking_tasks_queue
_90
SET replied_at = NOW(), replied = TRUE
_90
WHERE payload->>'ticket_id' = _ticket_id;
_90
ELSE
_90
RAISE NOTICE 'Ticket % has no reply. Taking actions...', _ticket_id;
_90
-- Perform actions for no reply
_90
SELECT * INTO _task FROM public.checking_tasks_queue
_90
WHERE payload->>'ticket_id' = _ticket_id AND status = '' AND due_time <= NOW()
_90
ORDER BY due_time ASC
_90
LIMIT 1;
_90
_90
IF FOUND THEN
_90
RAISE NOTICE 'Sending Slack notification for ticket %', _ticket_id;
_90
-- Use EXCEPTION to handle duplicate keys
_90
BEGIN
_90
INSERT INTO post_to_slack_log(payload) VALUES (_task.payload);
_90
PERFORM slack_post_wrapper(_task.payload);
_90
EXCEPTION
_90
WHEN unique_violation THEN
_90
RAISE NOTICE 'Duplicate entry for ticket %. Skipping...', _ticket_id;
_90
WHEN OTHERS THEN
_90
RAISE NOTICE 'Error while inserting into post_to_slack_log. Skipping...';
_90
RAISE NOTICE '% %', SQLERRM, SQLSTATE;
_90
END;
_90
-- Update the status to 'sent' after calling slack_post_wrapper
_90
UPDATE public.checking_tasks_queue
_90
SET status = 'sent'
_90
WHERE id = _task.id;
_90
ELSE
_90
RAISE NOTICE 'Task for ticket % not found!', _ticket_id;
_90
END IF;
_90
END IF;
_90
END LOOP;
_90
-- Release the advisory lock
_90
PERFORM pg_advisory_unlock(_lock_key);
_90
END;
_90
$$;

Posting SLA Enforcement Messages on Slack

SLA Buddy employs the Edge Function post_ticket_escalation to post SLA enforcement messages on Slack. This integration with PostgreSQL functions ensures streamlined execution and effective communication with support engineers.

Interactions with Support Members

SLA Buddy fosters seamless interactions between support engineers and the tool itself. Through Slack threads, support members can postpone the next steps in the escalation process by 30 min by @mentioning the bot in the thread. We also pushed a guide on how to interact with mentions in Slack as part of the bot's development.

The bot won't get disarmed until a response is sent in the ticket because we believe that even if the Support Engineer is unable to help the user, they can at least triage and set expectations for the next steps in the ticket like escalating to a specific team.

Watching Support Events

Another crucial aspect of SLA Buddy is its ability to monitor support events seamlessly. At Supabase we have the concept of Embedded Support when a member of the support team will work on more advanced tickets related to a specific Supabase product such as Edge Functions, Dashboard, Storage, Auth, Realtime etc.

The shift information about Support Engineers is hosted in a Google Calendar. This information is retrieved using the following function:


_35
CREATE OR REPLACE FUNCTION "public"."get_embedded_event_names"
_35
("date_param" timestamp with time zone DEFAULT "now"())
_35
RETURNS "jsonb"
_35
LANGUAGE "plpgsql" SECURITY DEFINER
_35
SET "search_path" TO ''
_35
AS $$
_35
DECLARE
_35
target_date timestamp with time zone := COALESCE(date_param, now());
_35
start_date timestamp with time zone := target_date + INTERVAL '2 hours';
_35
end_date timestamp with time zone := start_date + INTERVAL '1 day' - INTERVAL '1 millisecond';
_35
time_min text := to_char(start_date, 'YYYY-MM-DD"T"HH24:MI:SS.MS"Z"');
_35
time_max text := to_char(end_date, 'YYYY-MM-DD"T"HH24:MI:SS.MS"Z"');
_35
base_url text;
_35
api_url text;
_35
response jsonb;
_35
events jsonb; -- Change the declaration to jsonb
_35
embedded_event_names text[];
_35
BEGIN
_35
SELECT decrypted_secret
_35
INTO base_url
_35
FROM vault.decrypted_secrets
_35
WHERE name = 'calendar_base_url';
_35
_35
api_url := base_url || '&timeMin=' || time_min || '&timeMax=' || time_max;
_35
_35
select "content"::jsonb into response from extensions.http_get(api_url);
_35
events := response->'items'; -- Remove the typecast to ::jsonb
_35
_35
SELECT ARRAY_AGG(event->>'summary')
_35
INTO embedded_event_names
_35
FROM jsonb_array_elements(events) AS event -- Use jsonb_array_elements function
_35
WHERE (event->>'summary') ILIKE '%embedded%';
_35
RETURN COALESCE(to_jsonb(embedded_event_names)::text,'[]');
_35
END;
_35
$$;

Escalation Logic

SLA Buddy's escalation logic is defined in 4 steps of escalation going from a more narrow set of Support Engineers to the Head of Success. Here's the progression:

TargetLevelActionTimeline
Enterprise1Non-embedded support10 min
2On-shift support20 min
3@group-support35 min
4@head of success50 min
Teams1Non-embedded support1 hour
2On-shift support3 hours
3@group-support6 hours
4@head of success12 hours

Conclusion

SLA Buddy is a core operational component for Supabase support operations, keeping the whole team informed and engaged, and assisting with prioritizing tickets by their SLA restrictions.

We are firm believers in letting technology streamline operational work and allowing humans to focus on solving real problems, and SLA Buddy is a great example of that.

Final Thoughts

SLA Buddy started a passion project, born from a need to ensure that we're providing top-quality support to Supabase's users. We're big fans of personal exploration and kaizen incremental change.

And we're not done with SLA Buddy. It'll grow and evolve as Supabase grows, and our needs and the needs of our users change. Because it's built on Supabase features, it'll be easy to update and maintain, and it'll provide more and more value to our internal operations, we hope it might provide some value to you, too. We're also big believers in the Open Source community, and welcome any feedback or ideas you might have to make SLA Buddy even better for everyone.
